EXPECTED MARCH 2023
The Kinefinity MAVO LF MK2 comes in several lens mount and bundle variations:
- No Mount - Camera comes with no lens mount, if you already own a KineMOUNT or other attachable Kinefinity Active Mount.
- KineMOUNT - Kinefinity's exclusive universal native mount, combination with Kinefinity's various mounting adapters gives you versatility when it comes to lens choice.
- Active PL Mount - Standard Cine PL mount supporting any PL mount lens.
- Active E Mount - Allows you to attach any Sony E mount lens to the camera.
MAVO mark2 LF continues to be equipped with the same full-frame 3:2 CMOS image sensor as the popular MAVO Edge 6K , continuing the high frame rate of 6K 75fps and dual native ISO 5120/800. Compared with the previous product MAVO LF, which also has outstanding high sensitivity, MAVO LF mark2 can retain more highlight details and is suitable for shooting scenes with complex lighting. Combined with the wide viewing angle brought by the large format, it provides a shallower depth of field and a more cinematic picture.
MAVO mark2 provides more and updated lens support. In addition to continuing to be compatible with the unique KineMOUNT mount , which is convenient for users to quickly disassemble adapter mounts such as EF, PL and LPL mounts, MAVO mark2 also provides two commonly used lens mount options: the new native PL mount and electronic E-mount. Users can install and disassemble by themselves without correcting the flange distance.
The two cameras of MAVO mark2 adopt and simplify the MAVO Edge high-performance computing platform, greatly upgrade the image processing system, have independent dual SDI output, and record ProRes4444XQ to NVMe M.2 SSD in the camera, with fully integrated, exquisite lightweight design and high efficiency workflow, helping more photographers get a classic and efficient cinematography experience at a more affordable price.
Bayonet introduction
MAVO mark2 provides rich mount options and more and updated lens support.
- Native KineMOUNT: Allowing the camera to adapt to a variety of lenses is an inherent feature of KINEFINITY cameras. The first-generation camera KineRAW-S35 released in 2012 was equipped with a native short-flange distance KineMOUNT mount. MAVO mark2 is equipped with universal KineMOUNT, which is convenient for users to quickly release adapter mounts such as EF , PL and LPL mounts, and grasp every important opportunity of fast-paced shooting.
In addition to continuing to be compatible with the unique KineMOUNT mount, MAVO mark2 also provides two commonly used lens mount options: the new native PL mount and the electronic E mount . Users can install and disassemble by themselves without correcting the flange distance. The new two bayonets feature active locking, solid and long-lasting reliable cinema-grade design.
- Native PL mount: stable native design, precise locking of the lens, escorting movie-level shooting. Support Cooke/i protocol, accurately record on-site data, read focal length, aperture and depth of field information in real time and store them in the material, simplifying the post-production process.
- Native E-mount: supports most commonly used electronic E-mount lenses, supports users to adjust important parameters such as aperture, focal length, and focus through the camera body, and is consistent with the native PL mount of the Cooke/i protocol, and the monitoring screen presents lens elements data, and save lens parameters to footage when recording.
