SmallHD Cine 5 Monitor
SKU: SHD-16-0526

£1,243.00 ex VAT
£1,491.60 inc VAT
https://www.productiongear.co.uk/smallhd-cine-5-monitor.htmlSHD-16-05260
GBP1491.60



click to check availability



Cine 5 is lightweight, compact, and offers 2000nits brightness for full visibility even in direct sunlight. Optional camera-control functionality (software license and cable sold separately) allows users to start, stop, record, and more from the convenience of their Cine 5. Experience all your favorite PageOS 5 tools, functions, and settings pages on this field-ready 5-inch monitor.

1080p resolution ensures a clear look at your production, while 10-bit color processing offers excellent color accuracy. The added joystick and back button allow you to use this smart monitor in nearly all conditions, even on cold days when taking off your gloves is not an option.

Cine 5 is designed for high-end camera use – with bright imagery, optional Camera Control, and 2-pin locking power input – making it ideal for First ACs, Camera Operators, and DPs.

  • Field-ready, 5-inch monitor with 2000nits of brightness and joystick control
  • Model: 16-0526
  • Display: 5-inch Touchscreen, 1920x1080, 440 PPI
  • Input: 1x 3G-SDI [IN], 1x HDMI 2.0 (4Kp30) [IN],
  • Output: 1x 3G-SDI [IN/OUT], 1x HDMI 2.0 (4Kp30) [OUT], 1x 3.5mm Stereo Headphone Jack
  • Power Input: 2-pin Locking Power Input (10-34V DC, 1.6A)
  • Data I/O: 1x SD Card Slot, 1x Micro USB, 1x Locking USB



ENVIRONMENTAL
Item Weight:416g
Height:8.61cm
Width:13.41cm
Length/Depth:3.86cm
Mount Points:6x 1/4-20 Mounting Points
DISPLAY
Panel Type:Touch-Screen
Resolution:1920 x 1080
Aspect Ratio:16:9
Max Brightness:2000nits
Backlight Type:Edgelit
INPUT SIGNAL
3G-SDI Input Types:YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
HD-SDI Input Types:YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
SD-SDI Input Types:YCC 4:2:2 @ 10-bits: 480i59.94, 576i50
HDMI Input Types:YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4: 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200 YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50
Audio Input Types:HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels
OUTPUT SIGNAL
3G-SDI Output Types:YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
HD-SDI Output Types:YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
SD-SDI Output Types:YCC 4:2:2 @ 10-bits: 480i59.94, 576i50
HDMI Output Types:YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4: 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200 YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50
Audio Output Types:HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection
CONNECTOR TYPE
SDI:1x 3G-SDI (In), 1x 3G-SDI (In/Out)
HDMI:1x HDMI 2.0 (4Kp30) [In], 1x HDMI 2.0 (4Kp30) [Out]
Audio:1x 3.5mm Stereo Headphone Jack
DATA I/O
Storage Media:1x SD Card Slot
USB:1x Micro USB 1x Locking USB
POWER
Input:2-pin Locking Power Input (10-34V DC, 1.6A)
SOFTWARE
Pixel Zoom:Yes
Focus Assist:Yes
Peaking:Yes
False Colour:Customizable False Color Overlays
Waveform:Customizable 4K Waveform w/Region of Interest Highlighting (Coming Soon)
Custom LUTS:17pt 3D-LUT on Output/Input 33pt 3D-LUT on Output/Input
  • 1 x SmallHD Cine 5 Monitor
