| CAMERA FEATURES |
| Sensor Type: | 4/3" WDR CMOS Sensor |
| Sensor Size: | 19.0 x 13.0 mm |
| Effective Pixels: | 10.28M |
| Dynamic Range: | 13~15 Stops (Z-Log2) / 16 Stops (with WDR activated) |
| Lens Mount: | MFT mount (interchangeable) |
| Microphone: | Built-in Stereo Microphone |
| RECORDING |
| Resolution: | 4096 x 2160 (C4K) / 3840 x 2160 (4K)
4096 x 1728 (C4K 2.4:1) / 3840 x 1620 (4K 2.4:1)
3696 x 2772 / 3312 x 2760
2704 x 1600 / 1920 x 1080 |
| Frame Rate: | 59.94 / 50 / 29.97 / 25 / 24 / 23.98 fps |
| Max Variable Frame Rate: | 120 fps for 4096 x 2160 (H.265 only)
120 fps for 3840 x 2160 (H.265 only)
150 fps for 4096 x 1728 (H.265 only)
160 fps for 3840 x 1620 (H.265 only)
160 fps for 2704 x 1600 (H.265 only)
59.94 fps for 3696 x 2772
59.94 fps for 3312 x 2760
240 fps for 1920 x 1080 (H.265 only) |
| Max Bit Rate: | H.265 / H.264
300 Mbps for 4096 x 2160 / 3840 x 2160 / 4096 x 1728 / 3840 x 1620 / 3696 x 2772 / 3312 x 2760 / 2704 x 1600
200 Mbps for 1920 x 1080 |
| Colour Bit Depth: | 10-bit (H.265) & 8-bit (H.264) |
| Video Encoder: | 12-bit ProRes Raw / 12-bit ZRAW (partial debayer) / Proxy / H.265 main 10 profile / H.264 high profile |
| Audio Format: | 16-bit 48 kHz |
| Audio Encoder: | AAC / PCM (for MOV only) |
| File Format: | MOV / MP4 |
| Record Mode: | Video / Time Lapse Video |
| SETTINGS |
| ISO: | Auto, Manual (500 ~ 102400 / 250 ~ 51200 with WDR activated), Native ISO: 500 / 2500 (250 / 1250 with WDR activated) |
| Shutter: | Shutter Speed: Auto, Manual (up to 1/8000”) or
Shutter Angle: Auto, Manual (1° ~ 360°) |
| White Balance: | Auto, Preset, Manual (2300K ~ 7500K) |
| Focus Mode: | MF / AF / CAF |
| Image: | Brightness / Contrast / Saturation / Sharpness |
| Image Profile: | Rec.709 / Z-Log2 / FLAT / HLG |
| Audio: | Audio In / Out Level |
| Time Code: | Current Time / Manual Input / External Input |
| STORAGE |
| Media: | CFAST 2.0 |
| File System: | exFAT |
| CONNECTIVITY |
| HDMI: | HDMI 2.0 Type A (video output up to C4K @60fps) |
| USB: | USB 3.0 Type C for camera control & data transfer only |
| COM: | DB-9 connector, supports RS-232 |
| Remote Control: | 2.5 mm jack socket (Sony LANC compatible) |
| Audio In: | 3.5 mm stereo jack socket for active microphone only, or 5-pin LEMO port for dual channel XLR microphone (requires additional XLR audio connector) |
| Audio Out: | 3.5 mm stereo jack socket |
| Wi-Fi: | 5G Wifi |
| Ethernet: | Gigabit Ethernet port for control, setting & live streaming |
| POWER |
| Battery: | Sony NP-F series compatible (Battery not included) |
| Power Input: | DC 6.8V ~ 16.8V (2-pin LEMO socket), with LEMO connector |
| PHYSICAL |
| Material: | Aluminum Alloy |
| Weight: | 1090g (EF mount) / 1160g (PL mount) / 930g (MFT mount) |
| Dimensions: | 91.20mm x 99.25mm x 95.60mm (without lens) |
| ENVIRONMENT |
| Storage Temperature: | -20°C ~ 60°C |
| Operation Temperature: | 0°C ~ 40°C |
