CONNECTIONS |
Analog Audio Inputs: | 2 x remote controlled XLR/TRS microphone inputs with 48v phantom power / instrument preamps. 8 x +24dBu balanced analog inputs. |
Analog Audio Outputs: | 12 x +24dBu balanced analog outputs with mute protection. |
Digital Audio Inputs: | 9 x fully transformer coupled AES stereo digital inputs. 1 x S/PDIF input with sample-rate conversion. |
Digital Audio Outputs: | 11 x AES stereo digital outputs. 1 x stereo digital S/PDIF output. Standard 25pin Tascam interface for Analog and AES looms. |
Sync Input: | 1 x 75 ohm BNC Reference input. Tri‑Sync or Black Burst. 1 x 75 ohm BNC word clock input. |
Sync Output: | 1 x 75 ohm BNC Reference loop out. Tri‑Sync or Black Burst. 1 x 75 ohm BNC word clock regenerated output. Sync to all common frame rates and formats including HD Tri‑level sync, video sync, word‑clock and AES/EBU. |
Device Control: | 1 x RS-422 9-pin machine control input. 1 x RS-422 9-pin machine control output. |
Timecode: | Timecode input and output with regeneration. |
MIDI: | For future use |
GPIO: | GPI and GPO connections for cough and ‘On‑Air’ control |
PRODUCT SPECIFICS |
Sample Rate: | 44.1, 48, 96, 192 kHz |
Max Input: | Inputs 1-2 (mic): +2.5dBu Inputs 1-2 (instrument): +24dBu Inputs 3-10 (Line): +24dBu |
Gain Range: | Inputs 1-2: Mic Inputs: 50dB gain range (+21.5 to +71.5dB) Inputs 1-2 : Instrument Setting: 50dB gain range (+0 to +50dB) |
MIC E.I.N (Unweighted): | Inputs 1-2: -127dBu @40dB (61.5dB) Gain: 150 ohm source, 20Hz - 20kHz THD+N (mic input) Inputs 1-2: <0.001%@ 1kHz, -1 dBFS at 0dB gain Inputs 1-2: <0.004%@ 1kHz, -1 dBFS at 40dB (61.5dB) gain |
THD+N (Line Input): | Inputs 1-2: <0.001%@ 1kHz, -1 dBFS after 0dB gain (unweighted) Inputs 3-10 : <0.001 % @ 1 kHz (unweighted) |
Dynamic Range (Line Input): | Inputs 1-2 : 108dB @ 0dB gain (unweighted) Inputs 3-10: 110dB (unweighted) |
Input Frequency Response: | +0.05/-0.05dB, 20Hz - 20kHz |
Input Impedance: | Inputs 1-2 (XLR) : 2k ohm Inputs 1-2 (1/4"): >1M ohm Inputs 3-10: 15k ohm |
Max Output: | Outputs 1-12: +24 dBu |
THD+N (Line Outputs): | Outputs 1-12: <0.002% |
Dynamic Range (Line Output): | Outputs 1-12 : 109 dB (unweighted) |
Output Frequency Response: | +0.05/-0.5dB, 20Hz - 20kHz |
Output Impedance: | Outputs 1-12 : 50 ohms |
OPERATING SYSTEMS |
Windows: | Windows 10 Creators Update
Windows 11 |
Mac: | Mac 13.0 Ventura,
Mac 14.0 Sonoma or later. |
POWER REQUIREMENTS |
Power Supply: | Internal 100 - 240V AC 50/60Hz with IEC C14 mains input. |
Power Usage: | 40W |
Power Management: | Automatically powered-on/off only when the Fairlight Audio Accelerator is powered on. |
PHYSICAL SPECIFICATIONS |
Dimensions: | 482 x 280 x 43mm / 18.97 x 11 x 1.74" |
Weight: | 4.1kg / 9lbs |
ENVIRONMENTAL SPECIFICATIONS |
Operating Temperature: | 0° to 40°C (32° to 104°F) |
Storage Temperature: | -20° to 60°C (-4° to 140°F) |
Relative Humidity: | 0% to 90% non-condensing |
