GENERAL |
Camera Type: | Interchangeable lens digital camera |
Lens Mount: | E-mount |
SIZE & WEIGHT |
Dimensions (Body Only): | 129.7 mm x 77.8 mm x 84.5 mm / 5 1/8" x 3 1/8" x 3 3/8" |
Weight (Body Only): | 715 g (1 lb 9.3 oz) |
POWER |
Power Consumption: | [Movie] Approx. 7.3W (with FE 28-70mm F3.5-5.6 OSS lens attached) [Still image] Approx. 3.4W (with FE 28-70mm F3.5-5.6 OSS lens attached) |
Battery Operating Time: | Approx. 95 min (Actual recording, CIPA standard) Approx. 135 min (Continuous recording, CIPA standard) Approx. 580 shots (still images, CIPA standard) |
OPERATION |
Operating Temperature: | -20°C to +55°C, -4°F to +131°F |
Storage Temperature: | 0°C to 40°C, 32°F to 104°F |
RECORDING FORMAT (VIDEO) |
XAVC HS: | [XAVC HS 4K] XAVC HS 4K 59.94p/50p 200Mbps 4:2:2 10bit MPEG-H HEVC / H.265, XAVC HS 4K 59.94p/50p 150Mbps 4:2:0 10bit MPEG-H HEVC / H.265, XAVC HS 4K 59.94p/50p/23.98p 100Mbps 4:2:2 10bit MPEG-H HEVC / H.265, XAVC HS 4K 59.94p/50p 75Mbps 4:2:0 10bit MPEG-H HEVC / H.265, XAVC HS 4K 59.94p/50p 45Mbps 4:2:0 10bit MPEG-H HEVC / H.265, XAVC HS 4K 23.98p 100Mbps 4:2:0 10bit MPEG-H HEVC / H.265, XAVC HS 4K 23.98p 50Mbps 4:2:2 10bit MPEG-H HEVC / H.265, XAVC HS 4K 23.98p 50Mbps 4:2:0 10bit MPEG-H HEVC / H.265, XAVC HS 4K 23.98p 30Mbps 4:2:0 10bit MPEG-H HEVC / H.265, XAVC HS 4K 119.88p/100p 280Mbps 4:2:2 10bit MPEG-H HEVC / H.265, XAVC HS 4K 119.88p/100p 200Mbps 4:2:0 10bit MPEG-H HEVC / H.265 |
XAVC S: | [XAVC S-I 4K] XAVC S-I 4K 59.94p 600Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I 4K 50p 500Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I 4K 29.97p 300Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I 4K 25p 250Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I 4K 23.98p 240Mbps 4:2:2 10bit MPEG-4 AVC / H.264, [XAVC S-I HD] XAVC S-I HD 59.94p 222Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I HD 50p 185Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I HD 29.97p 111Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I HD 25p 93Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S-I HD 23.98p 89Mbps 4:2:2 10bit MPEG-4 AVC / H.264, |
XAVC S-I: | [XAVC S 4K] XAVC S 4K 59.94p/50p 200Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S 4K 59.94p/50p 150Mbps 4:2:0 8bit MPEG-4 AVC / H.264, XAVC S 4K 29.97p/25p 140Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S 4K 23.98p 100Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S 4K 29.97p/25p/23.98p 100Mbps 4:2:0 8bit MPEG-4 AVC / H.264, XAVC S 4K 29.97p/25p/23.98p 60Mbps 4:2:0 8bit MPEG-4 AVC / H.264, XAVC S 4K 119.88p/100p 280Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S 4K 119.88p/100p 200Mbps 4:2:0 8bit MPEG-4 AVC / H.264, [XAVC S HD] XAVC S HD 59.94p/50p/29.97p/25p/23.98p 50Mbps 4:2:2 10bit MPEG-4 AVC / H.264, XAVC S HD 59.94p/50p/29.97p/25p/23.98p 50Mbps 4:2:0 8bit MPEG-4 AVC / H.264, XAVC S HD 59.94p/50p 25Mbps 4:2:0 8bit MPEG-4 AVC / H.264, XAVC HD 29.97p/25p 16Mbps 4:2:0 8bit MPEG-4 AVC / H.264, XAVC S HD 119.88p/100p 100Mbps 4:2:0 8bit MPEG-4 AVC / H.264, XAVC S HD 119.88p/100p 60Mbps 4:2:0 8bit MPEG-4 AVC / H.264, |
RECORDING FORMAT (AUDIO) |
Recording Format (Audio): | LPCM 2ch (48kHz 16bit) LPCM 2ch (48kHz 24bit) LPCM 4ch (48kHz 24bit) MPEG-4 AAC-LC 2ch |
RECORDING FRAME RATE |
XAVC HS: | [XAVC HS 4K] 3840x2160/119.88p, 100p, 59.94p, 50p, 23.98p |
XAVC S: | [XAVC S 4K] 3840x2160/119.88p, 100p, 59.94p, 50p, 29.97p, 25p, 23.98p [XAVC S-I HD] 1920x1080/59.94p, 50p, 29.97p, 25p, 23.98p |
XAVC S-I: | [XAVC S-I 4K] 3840x2160/59.94p, 50p, 29.97p, 25p, 23.98p [XAVC S-I HD] 1920x1080/59.94p, 50p, 29.97p, 25p, 23.98p |
RECORDING / PLAYBACK TIME |
XAVC HS: | [XAVC HS 4K] 59.94p/50p 200M When using CEA-G160T (160 GB) Approx. 85 minutes, When using CEA-G80T (80GB) Approx. 40 minutes, 59.94p/50p 150M When using CEA-G160T (160 GB) Approx. 110 minutes, When using CEA-G80T (80GB) Approx. 55 minutes, 59.94p/50p 100M When using CEA-G160T (160 GB) Approx. 170 minutes, When using CEA-G80T (80GB) Approx. 80 minutes, 59.94p/50p 75M When using CEA-G160T (160 GB) Approx. 220 minutes, When using CEA-G80T (80GB) Approx. 100 minutes, 59.94p/50p 45M When using CEA-G160T (160 GB) Approx. 340 minutes, When using CEA-G80T (80GB) Approx. 160 minutes |
XAVC S: | [XAVC S 4K] 59.94p/50p 200M When using CEA-G160T (160 GB) Approx. 85 minutes, When using CEA-G80T (80GB) Approx. 40 minutes, 59.94p/50p 150M When using CEA-G160T (160 GB) Approx. 110 minutes, When using CEA-G80T (80GB) Approx. 55 minutes, [XAVC S HD] 59.94p/50p 50M When using CEA-G160T (160 GB) Approx. 310 minutes, When using CEA-G80T (80GB) Approx. 150 minutes, 59.94p/50p 25M When using CEA-G160T (160 GB) Approx. 550 minutes, When using CEA-G80T (80GB) Approx. 390 minutes |
XAVC S-I: | [XAVC S-I 4K] XAVC S-I 4K 59.94p/50p When using CEA-G160T (160 GB) Approx. 25 minutes, When using CEA-G80T (80GB) Approx. 10 minutes, [XAVC S-I HD] 59.94p/50p When using CEA-G160T (160 GB) Approx. 75 minutes, When using CEA-G80T (80GB) Approx. 35 minutes |
Proxy Audio: | XAVC Proxy: AAC-LC, 128kbps, 2 channels |
Proxy Video: | 1280 x 720 (Approx. 6Mbps), 1920 x 1080 (Approx. 9Mbps), 1920 x 1080 (Approx. 16Mbps) |
RAW OUTPUT |
RAW Output: | HDMI: 4264 x 2408 (59.94p/50p/29.97p/25p/23.98p), 16bit |
Other Video Function: |
Video Functions: | Audio Level Display, Audio Rec Level, TC/UB, Creative Look, Gamma Display Assist, PAL/NTSC Selector |
CAMERA SECTION |
Sensor Type: | 35mm full frame (35.6 x 23.8 mm), Exmor R CMOS sensor |
Pixels: | Approx. 10.2 megapixels (effective) for movies, Approx. 12.1 megapixels (effective) for Still images, Approx. 12.9 megapixels (total) |
Sensitivity: | [Movie] ISO 80-102400 equivalent (ISO numbers up to ISO 409600 can be set as expanded ISO range.), AUTO (ISO 80-12800, selectable lower limit and upper limit), [Still image] ISO 80-102400 (ISO numbers up from ISO 40 to ISO 409600 can be set as expanded ISO range.), AUTO (ISO 80-12800, selectable lower limit and upper limit) |
Shutter Speed: | Movie: 1/8000 to 1/4 (1/3 steps), up to 1/60 in AUTO mode (up to 1/30 in Auto slow shutter mode) Still image: 1/8000 to 30 sec, Bulb |
SLOW & QUICK MOTION |
XAVC HS: | XAVC HS 4K: [NTSC mode] 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, [PAL mode] 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps |
XAVC S: | XAVC S 4K: [NTSC mode] 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, [PAL mode] 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps, XAVC S HD: [NTSC mode] 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, 240fps 2, [PAL mode] 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps, 200fps |
XAVC S-I: | XAVC S-I 4K: [NTSC mode] 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, [PAL mode] 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps, XAVC S-I HD: [NTSC mode] 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, 240fps 2, [PAL mode] 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps, 200fps |
WHITE BALANCE |
White Balance Modes: | Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent / Flash / Underwater / Color Temperature (2500 to 9900K) & color filter / Custom |
GAMMA |
Gamma Curve: | Off / PP1-PP11, Parameters: Black level, Gamma (Movie, Still, S-Cinetone, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color Phase, Color Depth, Detail, Copy, Reset |
LATITUDE |
Latitude: | 15+ stop (S-Log3) |
FOCUS SYSTEM |
Type: | Fast Hybrid AF (phase-detection AF / contrast-detection AF) |
Focus Point: | [Movie] AF-C, MF, [Still image] AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), Manual Focus |
Sensitivity Range: | EV-6 to EV20 (ISO100 equivalent with F2.0 lens attached) |
Focus Mode: | [Movie] AF-C, MF, [Still image] AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), Manual Focus |
Focus Area: | [Movie] Wide / Zone / Center / Flexible Spot / Expanded Flexible Spot, [Still image] Wide / Zone / Center / Flexible Spot / Expanded Flexible Spot / Tracking |
Other Focus Features: | [Movie] 627 points, [Still image] 35mm full frame: 759 points (phase-detection AF) |
EXPOSURE CONTROL |
Metering Sensitivity: | EV-3 to EV20 (at ISO100 equivalent with F2.0 lens attached) |
Exposure Modes: | [Movie] Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual (M) / Flexible Exp. Mode, [Still images] AUTO (iAuto), P, A, S, M |
RECORDING (STILL IMAGE) |
Recording Format: | JPEG (DCF Ver. 2.0, Exif Ver. 2.32, MPF Baseline compliant), HEIF (MPEG-A MIAF compliant), RAW (Sony ARW 4.0 format compliant) |
Image Size: | Image size [3:2] 35mm full frame L: 12M, M: 5.1M, S: 3.0M, APS-C L:5.1M, M: 3.0M, S: 1.3M, Image size [4:3] 35mm full frame L: 11M, M: 4.6M, S: 2.7M, APS-C L: 4.6M, M: 2.7M, S:1.1M Image size, [16:9] 35mm full frame L: 10M, M: 4.3M, S: 2.6M, APS-C L: 4.3M, M: 2.6M, S: 1.1M, Image size [1:1] 35mm full frame L: 8M, M: 3.4M, S: 2.0M, APS-C L: 3.4M, M: 2.0M, S: 0.8M |
PLAYBACK |
Playback Functions: | Index view, Folder selection (Date / Still / Movie), Photo capture, 4Ch audio monitoring, Auto Review (stills), Image orientation (stills), Protect (stills), Rating (stills), Display as Group (stills) |
INTERFACE |
Audio Input: | 3.5 mm Stereo minijack, XLR handle: [INPUT1][INPUT2] XLR/TRS-type 3-pin(female) (x2), line/mic/mic +48V selectable, Mic Reference -40 to -60 dBu / [INPUT3] 3.5 mm Stereo minijack) |
USB: | USB Type-C (x1, SuperSpeed USB 5Gbps (USB 3.2) compatible), Multi/Micro USB (x1) |
Headphone Output: | Yes (3.5 mm Stereo minijack) |
Speaker Output: | Built-in, monaural |
HDMI Output: | HDMI jack (Type-A), YCbCr 4:2:2 10bit / RGB 8bit |
Multi Interface Shoe: | With Digital Audio Interface |
Bluetooth: | Bluetooth Standard Ver. 5.0 (2.4GHz band)) |
MEDIA |
Media Type: | CFexpress Type A / SD card (x2), Simult. Rec, Sort, Auto Switch Media, Copy |
MONITORING |
LCD: | 7.5cm (3.0-type) type, approx. 1.44M dots, Opening Angle:Approx. 176 deg., Rotation Angle:Approx. 270 deg. |
BUILT-IN MICROPHONE |
Built-In Microphone: | Built-in, stereo |
FILE SYSTEM |
File System: | FAT12, 16, 32, exFAT |
ZOOM |
Zoom Function: | Zoom ring rotate, Clear Image Zoom ([Movie] Approx. 1.5x (4K), Approx. 2x (HD) [Still image] Approx. 2x ), Digital zoom ([Movie] 35mm full frame: approx. 4x, APS-C: approx. 4x, [Still image] 35mm full frame: L: approx. 4x, M: approx. 6.1x, S: approx. 8x, APS-C: L: approx. 4x, M:approx. 5.2x, S: approx. 8x), Smart zoom ([Still image] 35mm full frame: M: approx. 1.5x, S: approx. 2x, APS-C: M:approx. 1.3x, S: approx. 2x) |
STILL IMAGE FUNCTION |
Shutter: | Mechanical shutter / Electronic shutter |
Drive Modes: | Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket |
Continuous Shooting Speed: | Hi+: 10 fps, Hi: 8 fps, Mid: 6 fps, Lo: 3 fps |
Noise Reduction: | Long exposure NR: On/Off, available at shutter speeds longer than 1 sec., High ISO NR: Normal / Low / Off |
Flash Control: | Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adaptor for flash compatible with Auto-lock accessory shoe, Flash sync speed 1/250 sec. |
Other Still Image Function: | Electronic Front Shutter Curtain, Silent Shooting, Anti-flicker Shoot |
IMAGE STABILIZATION |
Type: | Image Sensor-Shift mechanism with 5-axis compensation (Compensation depends on lens specifications) |
Mode: | [Movie] Active / Standard / Off, [Still image] On / Off |
Compensation Effect (Still Images): | 5.5 stops (based on CIPA standard. Pitch/yaw shake only. With Planar T* FE 50mm F1.4 ZA lens mounted. Long exposure NR off.) |
CUSTOM FUNCTION |
Custom Function: | Custom key settings, My Menu, My Dial Settings, Reg. Custom Shoot Set |
LENS COMPENSATION |
Lens Compensation: | Peripheral Shading, Chromatic Aberration, Distortion |
WI-FI / NFC |
Supported Format: | IEEE 802.11a/b/g/n/ac |
Frequency Band: | 2.4GHz band/5GHz band |
Security: | WEP/WPA-PSK/WPA2-PSK |
NFC: | NFC Forum Type 3 Tag compliant |
FTP TRANSFER |
FTP Transfer: | Wired LAN (USB-LAN), USB Tethering, Wi-Fi |
